Description

1064nm 10W Detachable Diode Laser

Features：
10W output power
1064nm wavelength
Standard fiber coupling for 200μm/
0.22NA
Customer options：
Red aiming beam
Thermistor
Power PD
Fiber detector
Applications：
Dental

Dermatology

Therapeutic

Parameter:

Center wavelength:1044~1084nm

CW Output Power: 10W

Threshold current: 0.7A

Operating current: 9A

Operating voltage: 3.5V

Reverse Voltage: 5V

Slope Efficiency: 1.4W/A

Electrical-to-Optical Efficiency: 30%

Spectral width(FWHM):6nm

Wavelength Shift with Temperature: 0.3nm/℃

Fiber Data:

Buffer diameter: 400μm

Cladding diameter: 220μm

Core diameter: 200μm

Numeric aperture: 0.22

Others:

ESD:  500V

Storage Temperature（Non-operating）: -20~70

Lead Soldering Temp: 260℃

Lead Soldering Time: 10sec

Operating Case Temperature: 15~35℃

Relative Humidity: 15~75%

PD Data:

Current：200~2000

Thermistor：

10±3%/3477 (K Ω)/β(25℃)

Aiming Beam Data：

Output Power：2mW

Wavelength : 630~643nm

Voltage;  2.2V

Current:45~65mA

Please kindly check the datasheet:

1064nm 10W Detachable Diode Laser
