1330nm DFB Laser narrow linewidth Built In TEC Butterfly Diode




The 1330nm DFB built in TEC Butterfly Laser Diode is designed for broadcast and narrowcast analogue transmission in CATV and CWDM applications. The modules provide high output power while maintaining high linearity. The modules are housed in an industry standard hermetically sealed 14-pin butterfly package, which contains optical isolator, thermoelectric cooler, and power monitor photodiode.

Center wavelength 1310nm or customize;

High output power 10~100mW;

Integrated optical isolator;

DFB Laser, Single Frequency;

Single Mode Fiber, FC/APC or FC/PC Connector.

Fiber optic communication;

Laser sources;

Long reach analog communications systems;

CATV systems.
