With tinned pins extracted from new module. Packed in antistatic bag with datasheet. Rated at 4.3W continuous (3.0A), 3.5A max, in our tests capable of 5W. Fitted with static protection device.
From Manufacturers Datasheet:
Optical Output: 4.3W @3.0A
Max. Operating Current: 3.5A
Typical Operating Voltage: 4.5-4.9V
Package Size: 9mm
Built-in Static Protection
New extracted component packed in antistatic bag & supplied with datasheet.
Ball lens cap is secured with optical cement and may be removed (pliers and vice needed) to give open-can diode.
The ball lens projects a large spot, for a small spot the ball lens can be removed and a normal focusing lens used.
BRAND NEW Nichia NUBM08 445nm 4.75W+ Watt 9mm Laser Diode. The diodes are meticulously extracted from a new laser diode array.
This is a 455nm 4.75w blue laser diode extracted from brand new nichia nubm08 38w 455nm bank.
it has long cap with lens, two welded long pins–not cut pins.
the cw output we tested in our lab is 4.75w-5.5w, while the pulse output can reach 8.5w-9.5w.
we normally use it in our engraving laser modules.
wavelength: 455nm +-5nm
output: cw 4.75w
working voltage and current please check the datasheet attached.
- Laser engraving modules normally. It can engrave wood, plastic and furs but not for metal. RGB lasers will cut/engrave/mark on materials not reflect light.
- High output laser stage lighting on DJ, KTV and other stage lightings. Considering the very high output, we strongly recommend buyers use it on fat beam lasers.
