520nm 5mW Coaxial Packaged SM Diode Laser

Description

520nm 5mW Coaxial Packaged SM Diode Laser

Features:
520nm wavelength
5mW output power
4µm fiber core diameter
0.13N.A.

Parameter:

CW Output Power: 5mW

Threshold current: 50mA

Operating current: 150~160mA

Operating voltage: 7.3~8V

Reverse Voltage: 2V

Slope Efficiency: 0.25W/A

Electrical-to-Optical Efficiency: 0.1%

Center wavelength: 510nm~530nm

Spectral width(FWHM): 3nm

Wavelength Shift with Temperature: 0.2nm/℃

Fiber Data:

Buffer diameter: 250μm

Cladding diameter: 125μm

Core diameter: 4μm

Numeric aperture: 0.13NA

Fiber length:0.9~1.1

connector: FC/FA/SC/SA/SMA905/ST

Fiber Bend Radius: 40mm

Others:

ESD:  500V

Storage Temperature(Non-operating): -20~70

Lead Soldering Temp: 260℃

Lead Soldering Time: 10sec

Operating Case Temperature: 15~35℃

Relative Humidity: 15~75%

Please kindly check the datasheet:

520nm 5mW Coaxial Packaged SM Diode Laser
