1550nm SLED Light Source



Optical Communication
Optical Passive device testing
Spectrum analyses

High Precision ATC and APC Control Circuit
High stability and reliability
Broadband spectrum

Central wavelength (nm): 1650 ±10
Spectrum width (nm)(3dB) : ≥50
Output power (mw) : 2、10
Ripple: ≤0.2dB
Output power short term stability: ≤±0.01dB/15 min
Output power long term stability: ≤±0.03dB/8 hour
Operating mode : CW
Fiber pigtail: Single mode SMF-28
Output connector: FC/PC, FC/UPC or FC/APC
Operating temperature: 0℃ ~ 40℃
Storage temperature: -20℃ ~ 70℃
Power supply: 110/220V AC±10%, 50Hz, 20W
Dimensions (L×W×H) : 322×220×88
