VCSEL 850nm 25W Pulsed Laser Diode For Range Finder Sensors For Laser Curtain For 3D Sensing


SKU: N/A Categories: ,


850nm 25W VCSEL Pulsed Laser Diode For Range Finder Sensors For Laser Curtain For 3D Sensing


  • 850nm Multimode VCSEL
  • Good thermal conduction
  • Oxide Isolation Technology
  • 116 Apertures design
  • Modulation bandwidth>1Gbps
  • Relatively small emission area


  • 3D Sensing
  • Laser Curtain
  • Range finder sensors
  • Telescope distance meter
  • Lidars
  • Military applications

Notice 1.Stresses greater than those listed under ”Absolute Maximum Ratings” may cause permanent damage to the device.This is a stress rating only and functional operation of the device at these or other conditions above those indicated in the operations section for expended periods of time may affect reliability. 2. In its maximum rating diode laser operation could damage its performance or cause potential safety hazard such as equipment failure. 3. Electrostatic discharge is the main reason for the laser fault of the diode. Take effective precautions against ESD. When dealing with laser diodes, use the wrist strap, grounding work surface and strict antistatic technology.



Part Number Description
LD0850-C025-0120CBP-3535/TO18 850nm 25W VCSEL Pulsed Laser Diode

Ⅰ.Absolute Maximum Ratings

Parameter Rating
Storage Temperature -40 to 105℃
Case Operating Temperature -40 to 80℃
Relative Humidity 10% to 85%
Reverse Power Supply Voltage 5V
Maximum Forward Pulse Current 90A(Duty cycle 0.1% max.)
ESD Exposure(Human Body Model) 1000V
